Ultra-High Voltage Digital Latch Hall Effect Sensor
AEC-Q100、High chopping frequency、Robust EMC performance
The SC2919 family, produced with Ultra-High voltage BiCMOS technology, is a chopperstabilized Hall Effect Sensor that offers a magnetic sensing solution with superior sensitivity stability over temperature and integrated protection features.
SC2919-Q_EN.pdf
Characteristics and advantages
AEC-Q100 Certificated
Ultra-high voltage stress endurance up to 240V
Wide supply operating range: -4.0-120V
Operation from unregulated supply
Wide operating temperature range: -40~150℃
Superior temperature stability
High chopping frequency
Robust EMC performance
Small package： SOT23-3L (SO) 、TO-92S (UA)
Ordering Information
| Ordering Information | Mark | Option | BOP(Gs) | BRP(GS) | Ambient, TA(℃) | Package | Packing | Quantity |
|---|---|---|---|---|---|---|---|---|
| SC2919SO-N-TR-Q | 2919 | N | -70 | +70 | -40~150 | SOT23-3L | Reel | 3000/reel |
| SC2919UA-BK-Q | 2919 | S | +70 | -70 | -40~150 | TO-92S | Bulk | 1000/bag |
| SC2919UA-N-BK-Q | 2919 | N | 70 | -70 | -40~150 | TO-92S | Bulk | 1000/bag |
Product Application
Seat Motor
Proximity Switch
BLDC Motor
Solenoid Valve
The SC2919 family, produced with Ultra-High voltage BiCMOS technology, is a chopperstabilized Hall Effect Sensor that offers a magnetic sensing solution with superior sensitivity stability over temperature and integrated protection features.
